Made in China
Product features：With metal frame, the surface is imitated natural clay roof with multiple color and patterns, Kunvo solar roof tiles can perfectly march with traditional roofing , combine the functionality of a solar roofing and keep the architectural beauty of the roof.
| title | Parameters | title | Parameters |
|---|---|---|---|
| Dimensions | 1370 mm X 430 mm | Cell type | Mono c-Si |
| Effective size | 1338 mm X 390 mm | Rated Max.power (Pmax) | 90W±3% |
| Weight per module | 10kg | Current at max. power (Impp) | 6.28A |
| Weight per m² | 19.2kg | Voltage at max. power (Vmpp) | 14.43V |
| Front cover | 3.2 mm tempered glass | Short circuit current (Isc) | 6.24A±4% |
| Frame / Backsheet | anodised aluminium / Black,white | Open circuit voltage (Voc) | 17.36 V±3% |
| Junction box protection class | MC4 IP68 | Max. System voltage | 1500V DC |
| Cable cross section | 4 mm² | Operation temperature | -40℃ ~ 85℃ |
| Wind / Snow Load | 2400Pa/5400Pa | Tolerance（Tol） | 0/+5W |
| Protection Class | Class II |
